VPN Termination

VPN Terminations associate a VPN service with exactly one local attachment point:

  • a VLAN
  • a device interface
  • a virtual machine interface

This model is primarily intended for overlay and service-style VPN use cases where the VPN object describes the shared service and the VPNTermination records describe where that service is attached in the network.

For example, a VXLAN-based service can store its service-wide attributes on the VPN record, while individual VPNTermination records map that service to the relevant VLANs, switch interfaces, or VM interfaces that participate in it.

Validation Rules

Each VPN Termination must satisfy the following rules:

  • Exactly one of vlan, interface, or vm_interface must be set.
  • A given VLAN can belong to only one VPN Termination.
  • A given device interface can belong to only one VPN Termination.
  • A given VM interface can belong to only one VPN Termination.
  • VPNs whose service type is point-to-point are limited to two terminations.

These rules help keep the attachment model unambiguous and make it clear which local object is bound to which VPN service.

Relationship to VPN

The VPN object stores service-wide data such as:

  • the service identifier
  • the service type
  • status
  • optional free-form service metadata

VPNTermination stores the local binding of that service to a single object in Nautobot. This separation keeps shared service attributes in one place while still allowing the service to be attached at multiple points in the infrastructure.

Indicative Usage

Common examples include:

  • mapping a VXLAN or VXLAN-EVPN service to a VLAN
  • associating a service directly with a routed or switched device interface
  • associating a service with a VM interface in a virtualized environment
